DD502S | Steering axle

DD502S is a high-performance steering axle of the F5.0 series, adopting an I-beam structure, with a rated load of 5000kg (for heavy-duty demand).

It is equipped with a high-efficiency air brake system (adapted to 19.5° rim) as standard, and the key parameters are precisely optimized: fixed wheelbase of 2363mm to strengthen the stability, rim mounting distance of 2086mm for precise layout; main pin center distance of 1753mm to enhance the steering rigidity.

Exclusive design of 120+25mm front axle drop (the highest in the whole series), adapted with 7.50×19.5 rims and 245/70R19.5 wide base tires, the steering angle of the outer wheels reaches 49° (the top in the industry), and the bolts adopt 8-M20×1.5, which can satisfy the requirements of reliability and mobility of the commercial vehicles under complicated working conditions.

DD502S Product Features

  • Super Load Bearing: Flange-forged I-beam technology with load-bearing capacity covering 5.0 to 8.0 tons, suitable for ultra-heavy-duty scenarios such as ports and mines.

  • Heavy Load Braking: Standard equipped with large Ø420mm dual-chamber air brakes, with optional ABS and automatic adjusters, resistant to high temperatures and decay.

  • Structure Reinforcement: Wider wheelbase (1950-2200mm), axle housing made of high-strength alloy steel, increasing torsional resistance by 30%.

  • Long-term Maintenance: Integrated central lubrication system, upgraded sealing of key components, extending maintenance intervals to 5000km.

Technical Specifications

Category:Steering axle
Platform:DF502S
Basic Structure:I – Beam
Rated Load (kg):5000
Brake Structure/Specifications:Air brake/19.5″
Maximum External Width A (mm):2363
Rim Installation Distance B (mm):2086
Kingpin Center Distance C (mm):1753
Spring Distance D (mm):923
Front Axle Drop:120+25
Kingpin Inclination/Wheel Camber:9° / 0.5°
Inner Wheel Steering Angle/Outer Wheel Steering Angle:49°
Rim:7.50×19.5
Tire:245/70R19.5
Wheel Bolts:8-M20×1.5
Wheel Bolt Circle E (mm):φ275
Wheel Toe (mm):1 – 3mm
Air Chamber Interface Dimensions:NP1/4 、M1.6 × 1.5、Z1/4
Optional Information:Maintenance-free hub unit
Lead Time:15 – 30 Working Days
Payment Terms:T/T, L/C



coming soon

coming soon

coming soon

Model

Rated Load (kg)

Brake Structure Form/Specifications

Maximum External Width A (mm)

Rim

Tire

Wheel Bolts

DD502S5000Air brake/19.5″23637.50×19.5245/70R19.58 – M20×1.5
DF501S5000Air brake/φ400×130、 φ400×150、22.5″2173 – 25218.25×22.511.00R22.510 – M20×1.5
DF601S6000Air brake/φ400×150、22.5″2251 – 25388.25×22.511.00R22.510 – M22×1.5
DF701S7000Air brake/φ400×150、 φ410×180、22.5″2045 – 26458.25×22.5275/70R22.510 – M22×1.5
DF801S8000Air brake/φ410×180、22.5″2457 – 25039.00×22.5315/80R22.510 – M22×1.5
——END——

 Steering Axle General Information

CategorySteering AxleBasic Structure FormI – Beam
Rim Installation Distance B (mm)2086Kingpin Center Distance C (mm)1753
Spring Distance D (mm)932Front Axle Drop (mm)120 + 25
Kingpin Inclination/Wheel Camber9°/0.5°Inner Wheel Steering Angle/Outer Wheel Steering Angle49°
Wheel Bolt Distribution Circle E (mm)φ275Wheel Toe – in (mm)1 – 3mm
Air Chamber Interface SizeNPT1/4、M16、1.5、 Z1/4Optional InformationMaintenance – free Wheel Unit
——END——
