DF252S | Steering axle

DF252S is a high-performance steering axle of Dongfeng Dana F series, which adopts an I-beam structure and has a rated load of up to 2500kg (the highest in the series).
The core parameters are accurately adapted to the heavy-duty demand: wheelbase covers 1824.5-2106mm with ultra-wide adjustment, rim mounting distance 1565-1766mm with flexible layout; main pin center distance 1385-1552mm optimizes the steering performance, and the front axle drop 95mm strengthens the passability.
It is equipped with an oil brake system (supporting 15° and 16° rim specifications), 215/75R17.5 wide base tires and 17.5″ rims, and the steering angle of the outer wheels reaches 38.4°, and the bolts adopt 5-M18×1.5, which can satisfy the requirements of stability and load bearing under complicated working conditions.

DF252S Product Features

Adopting the integral reducer housing design to increase rigidity and reduce the risk of oil leakage;
The gears adopt the world’s leading high power density design technology, are lighter in weight, have a wide tooth surface design, are more than 10mm wider than competing products, and have lower noise;
Standard forced gear lubrication pump and oil channel inside the main shaft can effectively improve the lubrication of the shaft difference system, reduce shaft difference and cylindrical gear failure, and improve transmission efficiency;
Adopting fluororubber high performance oil seal design, tested according to DANA standards, the seal is more reliable
Optional maintenance-free wheel hub unit meets the matching requirements of high-grade commercial vehicles.

Technical Specifications

Category:	Steering Axle
Platform:	DF252S
Basic Structure:	I – Beam
Rated Load (kg):	2500
Brake Structure/Specifications:	Oil brake/15″ 、 16″
Maximum External Width A (mm):	1824.5 – 2106
Rim Installation Distance B (mm):	1565 – 1766
Kingpin Center Distance C (mm):	1385 – 1552
Spring Distance D (mm):	750 – 860
Front Axle Drop (mm):	95
Kingpin Inclination/Wheel Camber:	12°/0.5°
Inner Wheel Steering Angle/Outer Wheel Steering Angle:	38.4°
Rim:	17.5
Tire:	215 / 75R17.5
Wheel Bolts:	5-M18×1.5
Wheel Bolt Circle E (mm):	φ203.2
Wheel Toe (mm):	1 – 3
Air Chamber Interface Dimensions:	NP1/4
Lead Time:	15 – 30 Working Days
Payment Terms:	T/T, L/C

coming soon

Model	Rated Load (kg)	Brake Structure Form/Specification	Maximum Outer Width A (mm)	Rim	Tire	Wheel Bolt
DF252S	2500	Oil brake/15″、 16″	1824.5 – 2106	6.00×17.5	215/75R17.5	5 – M18×1.5
DF271S	2700	Air brake/φ310×100、 17.5″	1754 – 2468	6.00×17.5	215/75R17.5	6 – M18×1.5、 6 – M20×1.5
DF302S	3000	Air brake/φ310×120、 φ310×130、17.5″	2053 – 2129	6.00×17.5	215/75R17.5	6 – M18×1.5
DF321S	3200	Air brake/φ400×130、 17.5″/19.5″	2180 – 2285	7.00T – 20	9.00 – 20 – 16PR	8 – M20×1.5
——END——

Basic information of truck steering axle
Category	Steering Axle	Basic Structural Form	I – beam
Rim Mounting Distance B (mm)	1565 – 1766	Kingpin Center Distance C (mm)	1385 – 1552
Spring Distance D (mm)	750 – 860	Front Axle Drop	95
Kingpin Inclination Angle/Wheel Camber Angle	12°/0.5°	Inner Wheel Steering Angle/Outer Wheel Steering Angle	38.4°
Wheel Bolt Distribution Circle E (mm)	φ203.2	Wheel Toe – in (mm)	1-3
Air Chamber Interface Size	NPT1/4
