DF801S | Steering axle

DF801S is the flagship I-beam steering axle of F8.0 series, with a rated load of 8000kg (the highest in the series).
It is equipped with a heavy-duty grade air brake system (φ410×180 brake drum, 22.5° rim) as standard, with wheelbase accurately adapted to the narrow layout of 2457-2503mm, and rim mounting distance of 2034-2078mm precision tolerance control.
The center distance of the main pin is fixed at 1817.6mm to optimize the rigid support, 95+37mm front axle drop enhances the passability of complex road surfaces.
Adapted with 9.00×22.5 high-strength rims and 315/80R22.5 wide-base tires (the widest cross-section in the industry), the steering angle of the outer wheels is 45°, and the bolts are distributed with a round φ335 reinforced structure, which is specially designed to provide the top stability for the extreme working conditions of heavy loads.

DF801S Product Features

Super Load Bearing: Flange-forged I-beam technology with load-bearing capacity covering 5.0 to 8.0 tons, suitable for ultra-heavy-duty scenarios such as ports and mines.
Heavy Load Braking: Standard equipped with large Ø420mm dual-chamber air brakes, with optional ABS and automatic adjusters, resistant to high temperatures and decay.
Structure Reinforcement: Wider wheelbase (1950-2200mm), axle housing made of high-strength alloy steel, increasing torsional resistance by 30%.
Long-term Maintenance: Integrated central lubrication system, upgraded sealing of key components, extending maintenance intervals to 5000km.

Technical Specifications

Category:	Steering axle
Platform:	DF801S
Basic Structure:	I – Beam
Rated Load (kg):	8000
Brake Structure/Specifications:	Air brake/φ410×180、22.5″
Maximum External Width A (mm):	2457-2503
Rim Installation Distance B (mm):	2034-2078
Kingpin Center Distance C (mm):	1817.6
Spring Distance D (mm):	850-900
Front Axle Drop：	95+37
Kingpin Inclination/Wheel Camber:	7° / 1°
Inner Wheel Steering Angle/Outer Wheel Steering Angle:	45°
Rim:	9.00×22.5
Tire:	315/80R22.5
Wheel Bolts:	10-M22×1.5
Wheel Bolt Circle E (mm):	φ335
Wheel Toe (mm):	1 – 3mm
Air Chamber Interface Dimensions:	NP1/4 、M1.6 × 1.5、Z1/4
Optional Information：	Maintenance-free hub unit
Lead Time:	15 – 30 Working Days
Payment Terms:	T/T, L/C

coming soon

Model	Rated Load (kg)	Brake Structure Form/Specifications	Maximum External Width A (mm)	Rim	Tire	Wheel Bolts
DF801S	8000	Air brake/φ410×180、22.5″	2457 – 2503	9.00×22.5	315/80R22.5	10 – M22×1.5
DD502S	5000	Air brake/19.5″	2363	7.50×19.5	245/70R19.5	8 – M20×1.5
DF601S	6000	Air brake/φ400×150、22.5″	2251 – 2538	8.25×22.5	11.00R22.5	10 – M22×1.5
DF701S	7000	Air brake/φ400×150、 φ410×180、22.5″	2045 – 2645	8.25×22.5	275/70R22.5	10 – M22×1.5
DF501S	5000	Air brake/φ400×130、 φ400×150、22.5″	2173 – 2521	8.25×22.5	11.00R22.5	10 – M20×1.5
——END——

Basic information of truck steering axle
Category	Steering Axle	Basic Structure Form	I – Beam
Rim Installation Distance B (mm)	2034 – 2078	Kingpin Center Distance C (mm)	1817.6
Spring Distance D (mm)	850 – 900	Front Axle Drop (mm)	95 + 37
Kingpin Inclination/Wheel Camber	7°/1°	Inner Wheel Steering Angle/Outer Wheel Steering Angle	45°
Wheel Bolt Distribution Circle E (mm)	φ335	Wheel Toe – in (mm)	1 – 3mm
Air Chamber Interface Size	NPT1/4、M16×1.5、Z1/4	Optional Information	Maintenance – free Wheel Unit
