EP-Axle19C/Bus Electric Drive Axle
The EP-Axle19C is Dongfeng Dana Axle’s fourth-generation pure electric drive axleEmbracing the R&D philosophy of “Innovation Drives, Leading the Future,”
it is tailored for pure electric buses and city buses. It features dual wheel-mounted motors, a split C-arm structure, and a two-stage gear reduction. It uses the new EP-Axle branding.
The EP-Axle19C is designed for use in the 10-12m low-floor city bus market.
We provide full life cycle services for all customers, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
EP-Axle19C/ Product Features
Easy to Layout: Fully interchangeable with mainstream manufacturers’ interfaces and dimensions, enabling a low-floor configuration with a 20-70mm wider tunnel than domestic competitors.
High Economy: The overall efficiency of the transmission system is improved by 1%, reducing the system weight by over 100kg, effectively increasing driving range.
High Comfort: Cab noise levels do not exceed 68dB, providing a more pleasant driving experience.
Low Maintenance Costs: The axle assembly is warrantied for 5 years or 200,000 kilometers, and maintenance-free wheel ends are used, resulting in higher availability and lower maintenance costs.
Technical Specifications
| Model: | EP19C |
| Rated Load (kg): | 13000 |
| Axle Housing Type: | Casting |
| Rim Mounting Distance A (mm): | 1837 |
| Spring Distance B (mm): | 1510 |
| Left-to-Right Center Distance (mm): | 980 |
| Maximum Torque (Nm): | 18000 |
| Speed Ratio: | 20.05 |
| Motor Voltage (V): | 650/576 |
| Motor Peak/Rated Power (kW): | 150/95, 130/70 |
| Motor Peak/Rated Torque (Nm): | 550/275, 450/225 |
| Motor Maximum/Rated Speed (rpm): | 12000/3300, 10000/3300 |
| Brake Specifications: | Air Brake/22.5″ |
| Applicable Rim: | 8.25X22.5 |
| Applicable Tire: | 275/70R22.5 |
| Wheel Bolt Circle (C) (mm): | φ335 |
| Wheel Bolt: | 10-M22x1.5″ |
| Lead Time: | 15 – 30 Working Days |
| Payment Terms: | T/T ,L/C |
Model | Load (kg) | Axle Type | Rim Mounting Distance A (mm) | Spring Distance B (mm) | Maximum Torque (Nm) | Speed Ratio |
| EP-Axle19C | 13000 | Casting | 1837 | 1510 | 18000 | 20.05 |
| EP-Axle19C2 | 13000 | Cast | 1837 | 1510 | 19256 | 25.338 |
| EP-Axle13 | 8500 | Punch Welding | 1832 | 980 | 13000 | 19.89 |
| EP-Axle6 | 3500 | Casting | 1496-1612 | 850-952 | 5700 | 16.5 |
| EP-Axle5 | 3500 | Expansion Type | 1571 | 952 | 5400 | 15.58 |
| ——END—— | ||||||
Basic information of Bus Electric Drive Axle | |||
| Push-up center distance (mm) | 980 | Motor Voltage (V) | 650/576 |
| Motor peak/rated power (kW) | 150/95, 130/70 | Motor peak/rated torque (Nm) | 550/275, 450/225 |
| Motor maximum/rated speed (rpm) | 12000/3300, 10000/3300 | Brake specifications | Air brake/22.5″ |
| Applicable Rim | 8.25×22.5 | Applicable Tire | 275/70R22.5″ |
| Wheel Bolt Circumference (mm) | p335 | Wheel Bolts | 10-M22×1.5″ |
| Optional Configurations | Maintenance-Free/Low-Maintenance Wheel Hub | ||
| ——END—— | |||

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
